CS120 Narrow Frame Outward Casement Window
A 34mm wide multi-chamber thermal barrier delivers superior insulation, enhanced comfort, and greater energy efficiency.
Request project reviewDesigned as a complete opening.
An innovative concealed sealing design combined with three continuous sealing layers delivers enhanced air tightness, water resistance and acoustic performance,ensuring confidence in all climates. Seamless frame-and-sash integration creates sleek lines and a minimalist, modern facade.Two profiles-sloped for a refined, soft look, or square for clean, geometric lines-suit a wide range of architectural styles.Integrated hardware channel embeds the transmission mechanism within the profile, reduces exposed components,with hardware and sealing systems arranged in separated zones,optional concealed handle or side-mounted handle.Available in subframe or narrow-frame versions, delivering flexible installation, reliable performance, and sleek, minimalist aesthetics.
- System depth
- 120 mm
- Opening
- Outward casement
- Profile Wall Thickness
- 2.0 mm
- Frame Sightline
- 26 mm
- Sash Sightline
- 56 mm
Final dimensions, performance and component selection are confirmed against the project drawings and local requirements.
